Navya Construction Hot Mix Plants

ASPHALT BATCH MIX PLANT MODEL FAB-1500 RAP ASPHALT HOT MIX BATCH TYPE PLANT capacity 120 TPH is ideally operating with 3 % moisture content. The plant is fully automatic electro-pneumatic computerized controlled panel and also manual override control.The plant Model FAB 1500 performed 120 ton per hour, a single batch of 1500 Kg with 80 cycles per hour. The capacity is based on mean density of 1.6 ton/m3 and hot mix temperature 150° C at mixer outlet. The rated production capacity is depend upon mix temperature, moisture percentage, aggregate density, filler moisture and controlled dust.When density or mix temperature is not as per the stated requirement, the production capacity may drop as a result.The plant is equipped with multiple assemblies which consisto Four Bin Feedero Primary Vibrating Screeno Slinger Conveyoro Dryer Drum-8000 MMo Hot Elevator Unito Vibrator Unito Pug Mill Unito Hotbin Unito Bag Houseo Duct Lineo Dust Cycloneo Exhauster - Batch Mix Planto Chimney For Exhauster-6 Mtr.o Bitumen Tank - IDH 30 Klo Bitumen Tank - DH 30 Klo Ldo Tank 18 KLo Diesel Tanko Filler Feeding Unito Bitumen Filter Assemblyo Bitumen Transfer Pump 3 Inch Assly.o Rap Single Bin Feedero Rap-elevatoro Rap Slinger Conveyoro Batch Mix Burner 25 HP With Pump-ing 7.5 HPo Batch Mix Control Panel-FAB-1500 -RAPo Thermic Oil Heater Unito Bitumen Transfer Pump 2’’(optional)o Ldo/fo Transfer Pump (optional) Key Features Of FABHIND Asphalt Batch Mix Planto Rap Recycle Asphalt Adding Provision. (optional)o Duel Fuel Burnero Pug Mill Mixtureo Skid Mounted Mixing Towero Bigger Hot Bino Hot Bin Cylinder
